Haier MRV II - Page 90

Part 3
Model
AV36NM
VERA
AV38NM
VERA
AV40NM
VERA
AV42NM
VERA
AV44NM
VERA
AV46NM
VERA
AV48NM
VERA
Capacity
（HP）
36 38 40 42 44 46 48
Gas
pipe(mm)
Φ38.1 Φ38.1 Φ38.1 Φ38.1 Φ38.1 Φ38.1 Φ38.1
Liquid
pipe
(mm)
Φ19.05 Φ19.05 Φ19.05 Φ19.05 Φ19.05 Φ19.05 Φ19.05
Oil
equalizati
on
pipe(mm)
Φ9.52 Φ9.52 Φ9.52 Φ9.52 Φ9.52 Φ9.52 Φ9.52
Balance
pipe
（mm）
Φ9.52 Φ9.52 Φ9.52 Φ9.52 Φ9.52 Φ9.52 Φ9.52
1.1.4 Additional refrigerant charging standard: refer to the following
table, and fill the refrigerant charging volume in the “ additional
refrigerant charging” list which on the front plate of outdoor unit.
1.1.4.1 MRV refrigerant charging standard
A． Refrigerant charging volume when out of factory
Outdoor
model
AV08M
VERA
AV10NM
VERA
AV12NM
VERA
AV14NM
VERA
AV16NM
VERA
Standar
d
charging
volume
10Kg 10Kg 16Kg 16Kg 16Kg
