- 10 -
Pin number Signal name Description
1 LED_R LAMP RED
2 LED_G LAMP GREEN
3
4 IR REMOTE CONTROL
5 GND GND
6 5V POWER FOR REMOTE
7 KEY1
8 KEY0
9 GND
Keypad and remote connector (12)
Speaker connector J11
Pin number Signal nameD escription
+KPSR+KPSR1
-KPSR-KPSR2
-KPSL-KPSL3
+KPSL+KPSL4
