12 49-5000477 Rev. 0
5. INSTALL WINDOW LOCKING
BRACKET AND FOAM TOP WINDOW
GASKET
Use Type B Screw to install the window lock bracket
on top of the bottom window.
.
A.
CAUTION
To prevent broken glass
or damage to windows,
on vinyl or other similarly
constructed windows,
attach the window locking
bracket to the window
side jamb with one Type B
screw.
B. Cut the foam top window gasket to the window
width.
C. Stuff the foam between the glass and the window
to prevent air and insects from getting into the
room.
NOTE: If the gasket supplied does not fit your
window, obtain appropriate material locally to
provide a proper installation seal.
Wood
Vinyl
INSTALLATION INSTRUCTIONS
