49-5000477 Rev. 0 9
Side Curtain
Frame
Type B (9)
Foam top window
gasket
Side Curtain
(2)
Top mounting rail
Air
conditioner
Window locking
bracket (1)
Side Brackets (2)
ÙÊÛÝÜÒ×ÌÕÞÍÎÍ
(Appearance may vary)
Left
Right
Type A (3)
INSTALLATION INSTRUCTIONS
