Super Match
SW2: wiring controller communication address
wiring controller
address
SW2-1 SW2-2 SW2-3 SW2--4
Master unit 0 0 0 0
Slave unit 1 1 0 0 0
Slave unit 2 0 1 0 0
Slave unit 3 1 1 0 0
----- ----- ----- ----- -----
Slave unit 15 1 1 1 1
In single split system
,
when the wired controller control more than 1 units, please set the indoor unit address by
adjusting the PCB DIP switch SW2 as above.In MAXI split system
,
no need to set the indoor unit address, just
keep the factory setting
（
SW2 :OFF/OFF/OFF/OF).
Note:
Static pressure value for AD09~24SS1ERA(N)(P) ,AD12/18/MS1ERA and AD24MS2ERA (selection by SW1-4
SW1-5 )
Static pressure(Pa) 1st 2nd 3rd 4th
AD**SS1ERA(N)(P) 0 10 20 30
AD12MS1ERA
AD18MS1ERA
AD24MS2ERA
10 30 50 70
10 30 50 70
10 30 50 70
10 30 50 70
10 30 50 70
10 30 50 70
