Super Match
Item Model AD24MS2ERA
Function cooling heating
Capacity KW 7.1(2.0~8.2) 8.0(2.5~8.5)
Sensible heat ratio 0.74 /
Total power input KW 2.19(0.6~2.6) 2.16(0.6~2.6)
Max. power input W
2600 2600
EER or COP W/W 3.23 3.71
Dehumidifying capacity 10
-
³×m³/h 2.5
Power cable H05RN-F 4G 6.0mm2
Power source N, V, Hz
1PH, 220-230V~, 50/60Hz
Running /Max.Running current A / A 10.5(2.3-12)/12 9.2(2.3-12)/12
Start Current A 3
Circuit breaker A / /
Indoor unit
Unit model (color) AD24MS2ERA
Fan
Type × Number CENTRIFUGALX2
Speed(H-M-L) r/min 950/860/760
Fan motor output/ input power W 85/111
Air-ow(H-M-L) m³/h 1050/840/630
Heat
exchanger
Type / Diameter mm inner grooved pipe/φ7.0
Row 3
Total Area m² 7.668
Dimension
External(L×W×H) mm×mm×mm 1050/720/250
Package(L×W×H) mm×mm×mm 1170/860/340
Drainage pipe (material , I.D./O.D.) mm
PVC 25/29
Controller
(O-Optional,S-Standard)
Wired YR-E14(S)/YR-E16(O)
Infrared YR-HD01(O)
Fresh air hole dimension mm NONE
Electricity Heater kW NONE
Sound power Noise level (H-M-L) dB(A) 53/51/49
Sound pressure Noise level (H-M-L) dB(A) 42/38/35
Pipe
Liquid Pipe(mm)
9.52
Gas Pipe(mm)
15.88
Connecting Method
ared
Weight (Net / Shipping) kg / kg 31.2/36.8
37
