Haier Super Match Series - Page 88

Super Match
4U30HS2ERA cooling capacity in relation to temperature
5000
6000
7000
8000
9000
10000
11000
15 20 25 30 35 40 43
Outdoor temperature DB.
Cooling capacity (W)
14/20
16/22
19/27
22/30
Indoor
temperature
WB./DB.
4U30HS2ERA heating capacity in relation to temperature
5000
6000
7000
8000
9000
10000
11000
12000
-15 -12.5 -10 -7.5 -5 -2.5 0 2.5 5 7.5 10 12.5 15
Outdoor temperature DB.
Heating capacity (W)
25
20
15
10
Indoor
temperatureD
B.
87
