Control panels
Control panel 1
A Key switch (ON/OFF)
B Horn button
Control panel 2
C Pilot lamp (yellow)
for brush pressure
D Pilot lamp (red) for max. filling
level of soiled water tank
E Pilot lamp (red) for parking brake
F Pilot lamp (red) for fault display
G Hourmeter/service display
H Pilot lamp for battery charge
condition
I Key for additional scrubbing and
vacuuming tool (ON/OFF) with pilot
lamp (green)
J Key for pre-sweeper (ON/OFF) with
pilot lamp (green), optional*
K Key for brush drive (ON/OFF) with
pilot lamp (green)
L Key for squeegee and suction
turbine (ON/OFF) with pilot lamp
(green)
M Key for water flow reduction with
pilot lamp (green)
N Key for water infeed with pilot lamp
(green)
O Key for water flow raising with pilot
lamp (green)
P Key for brush drive, suction turbine
(ON/OFF), with simultaneous brush
head/squeegee (UP/DOWN) opera-
tion with pilot lamp (green)
* If the Hakomatic B 910 is not equipped
with the pre-sweeper option this key is
inoperable. If depressed, the hourmeter
will display ”OP”.
