HAKO Hakomatic B910 (7744) - Battery Charge Warning Unit; Battery Systems; Charger Units

39
Battery charge
warning unit
(Low discharge sensor)
The Hakomatic B 910 is equipped
with a charge condition monitor to
preclude poor battery charge con
ditions. This monitor is integrated in
the electronic system and factory-set
for Sonnenschein ”Gel” maintenance-
free batteries.
Using other batteries requires modi-
fication of the low-discharge sensor
settings.
Note: The low-discharge sensor set-
tings should be carried out by your
local Hako service center.
Charger units
Power connection of the charger unit
is effected via the power supply with
earthing-contact plug.
Mains voltage: 230 V/AC
Mains protection: 10 or 16 A slow
Battery systems
Battery system A
Tray-type battery, 24 V/ 320 Ah
5
, PzS, Aquamatic 7450
automatic battery charger unit 24 V/35 A
characteristic line lUlola and lUloU, 230 V/AC 4003
Battery system B
Tray-type battery, 24 V/ 280 Ah
5
, PzS, maintenance-free 7451
automatic battery charger unit 24 V/35 A,
characteristic line lUlola and lUloU, 230 V/AC 4003
Battery set C
Drive battery 6 V/ 180 Ah
5
, maintenance-free 7411
Battery charger unit 24 V/35 A,
characteristic line lUlola and lUloU, 230 V/AC 4003
Cable set 7412
Battery bowl with holder 7723
Battery set D:
Battery, 6 V/240 Ah GiV 7401
Battery tray with cable set 7403
automatic battery charger unit 24 V/35 A,
characteristic line lUlola and lUloU, 230 V/AC 4003
Battery system E:
Battery exchange system for extended running times
Through battery 24 V/240 Ah, PzS, Aquamatic**) 7334.02
Insert for battery exchange system 7301
Trailer for battery exchange system**) 7302
Automatic battery charger 24 V/35 A,
characteristic line lUlola and lUloU, 230 V/AC 4003
**)2 = minimum quantity, to enable exchange
Tray-type battery dimensions:
length 424 mm (in direction of travel), width 522 mm, height 462 mm
