Operation
3 Operation
3.1 Method of operation
The Sweepmaster B500 is a machine
desi
gned to sweep and clean waste
from hard floors and carpets.
The side brush (Fig. 4/1) sweeps the
dirt from corners to a position in front of
the rotary brush (Fig. 4/2). The rotary
brush sweeps the larger particle dirt
overhead into the sweepings container
(Fig. 4/3). The finer dust picked up is
drawn up by the suction turbine, fed into
the filter system (Fig. 4/4) and filtered
out. Only dust-free air is fed back into
the ambient air.
The machine is equipped with mainte-
nance-free batteries (Fig. 4/5), a spe-
cially adapted, fully automatic battery
charger (Fig. 4/6) and a total discharge
signal transducer to protect it against
total discharge.
Please refer to the spare parts
catalogue on our internet site
at www.hako
.com for accesso-
ries, such as brushes and rota-
ry brushes.
Fig.4
