HAKO Sweepmaster B500 - Rotary Brush

30
Maintenance and Service
5.6 Rotary brush
1 Rotary brush
2
Fillister head self-tapping screws
3 Rotary brush segment
4 Sealing strips
5 Sweeping pattern adjusting lever
6 Timing belt
7Hood
8 Locking bolt
Fig.9
