HALE CBP - Page 60

Sec VI-4
Parts Lists
Booster
Item
No. Part no Qty Description
031-1120-00-0 AP GEAR (23 TEETH)
17 1
031-1760-00-0 AP50-37 PUMP GEAR 20T
18 1 037-1161-00-0 40FW DRIVE SHAFT
19 1 037-1750-01-0 AP50-37 STAINLESS PUMP SHAFT
20 1 044-0310-00-0 P75-171 AIR VENT
044-0840-00-0 2CBP DRIVE UNIT COVER
044-0601-01-0 CBP DU WATER MANIFOLD
21 1
044-0601-02-0 CBP DU WATER MANIFOLD (BRONZE)
22 1 046-0050-00-0 46DW "115" GASKET
23 1 046-0440-00-0 HP-W323 GASKET
24 1 046-5270-01-0 CBP D U GASKET
25 1 046-6271-00-0 AP BRG COVER GASKET
26 1 064-5070-01-0 PIN-5/32 X 2 LONG SST COTTER
27 1 077-2810-00-0 79S281 RETAINING RING
28 4 082-0203-02-0 3/8X1/4 COMP FIT SLF ALGN L170
29 2 082-0513-00-0 BUSHING-3/4 X 1/4 NPT
30 12 097-0810-01-0 WASHER-5/16 STL ZINC PL FLAT
31 1 101-0082-00-0 GEARBOX SERIAL NUMBER PLATE
35 1 110-7040-00-0 ZS-274 NUT-IMPELLER
115-0080-00-0 115-3 FLANGE (CI)
36 1
115-0080-01-0 115-3 FLANGE (BRONZE)
37 1 142-0510-00-0 20BP SQUARE SEAL RING
38 4 217-0201-00-0 1/4 NPT SQUARE HEAD STEEL PLUG
217-0401-00-0 PLUG-1/2 NPT M.I.
39 2
217-0401-01-0 PLUG-1/2 NPT BRASS
40 1 217-0401-08-0 PLUG-1/2 NPT M.I. MAGNETIC
41 2 250-0207-00-0 207K BEARING
42 1 250-0208-20-0 208M BEARING
43 1 250-0306-20-0 306W BEARING
44 1 296-2210-00-0 60R-296 OIL SEAL
45 1 296-2610-00-0 MG PUMP SHAFT OIL SEAL (CR)
46 1 296-5021-09-0 AP/MG MECH SEAL (WELDED SPRING)
47 2 321-0150-00-0 4D-321 CLEARANCE RING
48 1 604-0033-00-0 3/8 OD X.032 WALL COPPER TUBE
