HALE CBP - 2 CBP Pump

Sec VI-10
Parts Lists
Booster
031-0851-00-0 40FC8 DRIVE GEAR (46T)
031-0361-00-0 CBP DRIVE GEAR (51T)
031-0371-00-0 CBP DRIVE GEAR (71T)
24
031-0381-00-0
1
40FW DRIVE GEAR (74T)
031-0400-00-0 CBP-31-18 GEAR (18T)
031-0390-00-0 CBP-31-15 GEAR (15T)
25
031-0840-00-0
1
40FC8 PUMP SHAFT GEAR (23T)
26 037-0372-00-0 1 2CBP PUMP SHAFT
27 037-1161-00-0 1 40FW DRIVE SHAFT
28 044-0260-00-0 1 171-1/8 AIR VENT
29 044-0840-00-0 1 2CBP DRIVE UNIT COVER
30 046-0360-00-0 1 2CBP-W266 BODY GASKET
31 046-0370-00-0 2 2CBP-W185 GASKET
32 046-0380-00-0 2 2CBP-W355 GASKET
33 046-5190-00-0 1 4PT-72 GASKET-PUMP HEAD
34 046-5230-00-0 1 CBP-71D GASKET
35 046-5270-01-0 1 CBP D U GASKET
36 046-5351-00-0 2 2CBP GASKET
37 062-0190-00-0 1 2CBP-251 BEARING-CENTER
38 064-0608-02-0 1 03-64-04S SPRING PIN
39 064-6010-00-0 2 AB-68-3/4 DOWEL PIN
40 077-0870-05-0 1 78S87 RETAINING RING
41 077-0980-25-0 1 78SS98 RETAINING RING
42 077-1180-05-0 1 78S118 RETAINING RING
43 077-2810-00-0 1 79S281 RETAINING RING
44 097-0210-00-0 1 FZZ-396 WASHER
45 097-0810-01-0 12 WASHER-5/16 STL ZINC PL FLAT
46 097-3170-24-0 1 WS-04 STAINLESS BRG LK WASHER
47 101-0082-00-0 1 GEARBOX SERIAL NUMBER PLATE
110-1600-02-0 NUT-3/8-16 PLD HEX,
48
110-1600-06-0
8
NUT-3/8-16 300 SST HEX
49 110-2701-11-0 1 NUT-3/4-16 NYL LOCK STNLS JAM
Not
Shown
130-0020-00-0 2 2CBP-398 VANE-SUCTION
217-0101-00-0 PLUG-1/8 NPT BLACK M.I. OR EQV
50
217-0101-01-1
10
PLUG-1/8 NPT BRASS
217-0301-00-0 PLUG-3/8 NPT SQUARE HEAD
51
217-0301-01-0
5
PLUG-3/8 NPT BRASS
52 217-0401-00-0 1 PLUG-1/2 NPT M.I.
Item
No. Part no Qty Description
