Sec VI-12
Parts Lists
Booster
HYDRAULIC ADAPTER
Hydraulically driven booster pumps are equipped with a drive adapter. The adapter bolts to the
standard pump gearbox. Use the part list below for reference when contacting Hale Products for
service.
Figure 6-4 Hydraulic Adapter
Hydraulic Adapter Part List
Item Part Number Description
1 007-1930-00-0 Adapter
2 088-0560-00-0 Coupling
3 077-1370-00-0 Retaining Ring
4 296-2180-00-0 Oil Seal
5 018-1814-07-0 7/16 – 14x 1 ½” Nylon
Locking Screw (4)
