HALE CBP - CBP Pump

Sec VI-6
Parts Lists
Booster
CBP Series Pump
Item
#
Part
Number
Qty Description
001-0190-00-0 CBP-320LD BODY-VOLUTE(OPP.END)
001-0190-01-0 CBP-B320LD BODY-VOLUTE(O.E.)
001-0200-00-0 CBP-320LD BODY-VOLUTE ENG ROT
1
001-0200-01-0
1
CBP-B320RD BODY PUMP(ENG.ROT)
002-0170-00-0 CBP-2F HEAD-PUMP
2
002-0170-01-0
1
CBP-B2F HEAD-PUMP
004-0091-00-0 CBP2,3 GEARBOX HSG
3
004-0380-00-0
1
CBP4,5 GEARBOX HSG
4 008-0150-00-0 1 CBP-61D BEARING-CAP
016-0230-00-0 CBP-16L-6 1/2 IMPELLER OPP ENG R
5
016-0240-00-0
1
CBP-16L-6 1/2 IMPELLER ENG R
6 017-0300-00-0 1 SSA-95XD KEY
7 017-0500-00-0 1 CBP IMP. KEY
8 017-0590-00-0 1 40FW DRIVE KEY
018-1404-02-0 12 SCREW-5/16-18 X 1/2 ZINC PL
9
018-1422-02-0 6 SCREW 5/16-18 X 2-1/4 HX HD
10 018-1406-02-0 8 SCREW-5/16-18X3/4 PLD,SEE L170
11 018-1412-02-0 2 SCREW-5/16-18 X 1 1/4 ZINC PL
12 018-1607-07-0 8 SCREW-3/8-16X7/8 HX HD ZINC NY
13 018-2004-66-0 1 SCREW-1/2-13X1/2 SEE L,170
14 018-5002-00-0 4 SCREW-#4 X 1/4 PLD,SEE L,170
031-0851-00-0 CBP DRIVE GEAR (46T) .
031-0361-00-0 CBP DRIVE GEAR (51T)
031-0371-00-0 CBP DRIVE GEAR (71T)
15
031-0381-00-0
1
CBP DRIVE GEAR (74T)
16 037-1161-00-0 1 40FW DRIVE SHAFT.
037-1201-00-0 CBP3/4 PUMP SHAFT(18 TEETH).
037-1031-00-0 40FD8-2 PUMP SHAFT(2.00 RATIO)
17
037-1191-00-0
1
CBP5 PUMP SHAFT(15 TEETH)
18 044-0260-00-0 1 171-1/8 AIR VENT
044-0840-00-0 2CBP DRIVE UNIT COVER
044-0601-01-0 CBP DU WATER MANIFOLD
19
044-0601-02-0
1
WATER MANIFOLD (BRONZE)
20 046-0350-00-0 1 FZ-W323 GASKET-VOLUTE BODY
21 046-5190-00-0 1 4PT-72 GASKET-PUMP HEAD.
22 046-5230-00-0 1 CBP-71D GASKET
