HALNy HL-2BV - Technical Specification; Appendix A Acronyms and Abbreviations

HALNy HL-2BV Quick Installation Guide
9
5 Technical Specification
Main Technical Specifications
Standard
GPON Standard
ITU-T G.984.x and G.988
Rate
Uplink
1.25Gbps
Downlink
2.5Gbps
Interface
Optical interface
Single Mode
LAN port
RJ-45 10/100/1000Mbps MDI/MDIX Self
adaption
2.5G port
RJ-45 100/1000/2500Mbps MDI/MDIX Self
adaption
POTS port
RJ-11 FXS
Physical Characteristics and Environment Requirements
Power adapter input
100V～240V AC，50Hz～60Hz
Whole-device power supply
12V DC / 2A
Standard power consumption
<24W
Operating temperature
0˚C～45˚C
Operating humidity
10%~90% (non-condensing）
Dimension
L x W x H：112mm x 162mm x 42mm
Weight
<500g
Appendix A Acronyms and Abbreviations
GPON
Gigabit Passive Optical Network
FTTB
Fiber to the Building
FTTH
Fiber to the Home
OLT
Optical Line Terminal
ONU
Optical Network Unit
PON
Passive Optical Network
