4. H46 OVERVIEW
4.1. Lights
Trigger light
Result light
"Fail"
Result light
"Pass"
Battery status
4.2. Connectors
RJ45 connector for OBD module
connection
USB connector for
battery charge and
firmware update.
Display screen
Keyboard
Antenna
