HAMPTON BAY GFM00469A - Step 3: Inserting Tips into Bars

3
l
7
Assembly (continued)
Inserting the tips
Insert the end tips (L) into the side top bar (D). Repeat this step for the other side of the top bar (D).
Insert the center tips (Q) into the center lengthways bar (E).
Insert the inner tip (S) into the lengthways bar (C). Repeat this step for the other three lengthways bars (C).
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
C
C
S
S
S
3-1
3-2
3-3
E
Q
Q
Q
E
D
L
L
D
L
