Handicare 2000 - BATTERIES RC; POWER

20
The lift does
not move in
either
direction
Part 1
The thermal
fuse on the
pcb is hot
Code
“d”
The main
power relay is
welded close
Code
“E”
The main
power relay
did not close
Code
“H”
The main
power relay is
closed early
Code
“G”
Problem with
the brake
Code
“.11.”
Over current
Code
“L”
Current limit
exceed
Problem with
brake
Problem with
display
Board P1 is
faulty
Main board
isfaulty
Check motor
and track for
obstructions
There is a break
in the current
between
M13-1 or M13-2
and the brake
Standard resis-
tance between
40 – 70 ohm
Replace pack
Problem
with infrared
receiver
Code
“flashing”
Short circuit on
the com-muni-
cation circuit
Main board
is faulty
The batteries
are low
Overload The brake is
faulty
Main board
isfaulty
