37
The powered footrest
does not operate
No 24 V = between
M14 and ground
24 V= between
M14 and ground
The operation switch
S26 or S28 is faulty
Main switch S21 switched off
The emergency switch S34
is faulty
The board
P2 is faulty
The main switch S21 is faulty
The keyswitch S23
is faulty
There is a break in the current between
U15 or U17 and U7
Broken fuse 25 A
There is a break in the current between
M8-9,U8-2,U10-2, U11-2, U11-1, U10-1
and U18-3
There is a break in the current between
U7 and M21
Break in current between
M2, M3 and M14
There is a break in the current between
the powered footrest motor and M15
Flat batteries
The powered footrest motor
is faulty
There is a break
in the ground connection and M16
