34
The hinge is operated but the lift
does not move code “J”
The lift is at the top and the hinge
is operated
There is a stopping difference between
the remote up button and the parking
button. Adjust the top stop and advise
customer to use the up button
The lift is on the charge contact but not
on the top stop. The lift thinks he is at
the hinge point. Adjust the top stop.
Check the hinge activation bracket and
the roller/switch S22 on the lift
There is a stopping difference between
the remote up button and the parking
button. Adjust the top stop and advise
customer to use the up button.
There is a break in the current between
M25-1 and M25-2
Check that the charge contact and the
hinge activation bracket are correct
aligned
The lift is on the intermediate
chargepoint
