36
The powered swivel does not operate
The Voltage on the communication
circuit is 24V= or less than 8V=
The Voltage on the communication
circuit is between 8V= and 12V=
Operate the control
The voltage on the communication
is 24V=
There is a break in the current between
the powered swivel motor and M19
The emergency switch
S34 is faulty
There is a break in the current between
M8-9,U8-2,U10-2, vU11-2, U11-1,
U10-1 and U18-3
The powered swivel motor
is faulty
The dipswitch setting on P3
is wrong
The key switch
S23 is faulty
There is a break
in the ground connection M18
The power has not been turned off/on
after changing the settings (10 sec delay)
The main board P1
is faulty
Board P3 is faulty
The control is faulty
see page 23
The board P3 is faulty
The chair has been swiveled by hand,
reposition the chair by hand
There is break in the current between
M12 and M17
The 5 Amp fuse
is faulty
There is a break in the current between
M3 and M12
The lift is not
on the limit actuator
There is no charging voltage
see page 31
The limit switch circuit is faulty
see page 27
The voltage on the communication
circuit remains between 8V= and 12V=
The main board P1 is faulty
To Next Page
