Handicare 2000 - Lift Does Not Charge

Quick Reference Guide Handicare 2000
31
Lift does not
charge
Code “1”
Requires charge
Ride the lift to the
charge contacts*
No 33V= between
charge contact and
ground
Code “2”
Off charge
Code “U”
No float indication.
33V= charging
power supply is
disconnected
33V PSU faulty
Faulty contact strip
in the unit
The charging power
supply is not con-
nected to the mains
Break in the current
between the contact
strip and M10
Break in the current
from the charging
power supply to
the rail
33V = between
charge contact and
ground
Ride the lift to the
charge contacts*
Short circuit
between M10 and
ground
Ride the lift to the
charge contacts*
Code “7”
Low voltage
Code”r”
No charge
No 33V= between
M10 and ground
