23
Lift does not move in either direction
Code: Flat line (on charge) Code: 2 (off charge)
Connect the molex testing link
The voltage between M7-2 and ground is not 4,5 V The voltage between M7-2 and ground is 4,5 V
The voltage between M7-1 or M7-3 and ground is not
4,5 V when calling the lift
The main board P1 is faulty
The lift is on the end position go to Lift does not move
in 1 direction on page 25
There is a break in the current between:
M7-2,U1-2,U2-2,U6-2,U18, U19,U12-2, U13-2
This Main Board P1 is faultyThe joystick is faulty
One of the armrests is in the folded position
An armrestswitch S29 or S30 is faulty
To Next Page
