4
2. Display codes
Right hand
Code Meaning Page
None Power off 24
− Charging, joystick failure 23,26
0 General safety line activated 22
1 Requires charge 31
2 Off charge 31
3 Bottom track limit activated 27
4 Bottom safety edge activated 29
5 Top track limit activated 28
6 Top safety edge activated 30
7 Low battery voltage 31
8 UP travel direction 21
9 DOWN travel direction 21
A Hinge open 35
b Toggle switch active at power up 21
C IR address fail 32
d Relay not open 20
E Relay not closed 20
F Brake semi-conductor failed 21
G Brake not connected 20
H Relay not open (pre-delay) 20
J Hinge interlock switch fault 34
L Current limit exceeded 20
n Lift driving at half speed 38
o Default Eprom 21
r Power supply fault during charging 31
U Power supply fault when battery on float 31
y Main board hardware fault 21
.||. Overcurrent 20
