12 | General description
E
G G
L
M
N
G
F
C
B
D
A
K
F
J
H
I
M
I
A
F
J
H
K
M
C
B
D
Trophy 20 UM 04
Trophy 20 UM 03
3.1 Main components
The scooter is equipped with, or can be
equipped with, the following main components:
A. Seat: this is where the user sits
B. Backrest: supports the user’s back
C. Headrest: supports the head
D. Armrest: supports the arms
E. Steering column: the control panel and all of
the control keys and levers are located on the
steering column
F. Lights: the lights should be switched on when
driving in the dark
G. Indicator lights: indicate changes in direction
while driving
H. Detachable basket: for the transportation of
personal belongings
I. Front wheel: front wheel with suspension
J. Front bumper: protects the front wheel on
collision
K. Rear wheels: rear wheels with suspension
L. Anti-tip wheels: wheels to prevent the scooter
from tipping over backwards on slopes
M. Attachment points: points of attachment for
securing the scooter
N. Brake lights: automatic activated when
braking
Various elements and components on the
scooter can be adjusted for optimal seating
comfort.
3.2 The user
The dealer must give you clear instructions
before you start operating the product
independently.
Your fi rst test drives of the Trophy 20 are
best carried out under the supervision of an
experienced dealer.
The Trophy 20 has a maximum speed of 12
km/h (country specifi c).
Warning:
Ensure that you are fully acquainted with the
contents of this manual before starting to drive
the Trophy 20
