Technical specifi cations | 37
8 Technical specifi cations
8.1 CE declaration
The product complies with the regulations of the Medical Devices Directive and therefore
bears the CE mark.
Approvals
The product meets the following requirements:
• EN12184; 2009 Electrically powered wheelchairs and scooters, class B.
• ISO7176-8 Requirements for static, impact and fatigue strengths.
• ISO7176-9 Climatic tests for electric wheelchairs and scooters.
• ISO7176-14 Requirements and test methods for power and control systems for electric
wheelchairs.
• ISO7176-16 Requirements for resistance to ignition of upholstered parts.
The product has been EMC-approved (for electromagnetic compatibility) in accordance with EN12184.
(2009)
8.2 Trophy 20 product specifi cations
Model Trophy 20 3 wheels (3W)
Trophy 20 4 wheels (4W)
Maximum user weight 160 kg (25.2 stone)
Description 3W 4W
Total length mm (inches) 1265 (49.8) 1265 (49.8)
Total width mm (inches) 660 (26) 660 (26)
Minimum height* mm (inches) 740 (29.1)* 740 (29.1)*
Total weight excluding batteries kg (stone) 92 (14.5) 102 (16.1)
Total weight including batteries (74 Ah C20) kg (stone) 140 (22) 150 (23.6)
Weight of heaviest component kg (stone) 70 (11) 80 (12.6)
Static stability in the downward direction ° > 13 > 13
Static stability in the upward direction ° > 13 > 13
Lateral static stability ° > 13 > 13
Distance range (ISO 7176-4)** km (miles) 45 (28) 45 (28)
Dynamic stability (max. safe slope) ° 9 9
Maximum speed forwards km/h (mph) 6 / 12 (3.7 / 7.5) 6 / 12 (3.7 / 7.5)
Back angle, Captain Seat ° 0 / 103 / 126 0 / 103 / 126
Seat depth, Captain Seat mm (inches) 445 (17.5) 445 (17.5)
Seat width, Captain Seat mm (inches) 457 (18) 457 (18)
Back height (excl. headrest), Captain Seat mm (inches) 406 (16) 406 (16)
Seat height (to platform), Captain Seat*** mm (inches) 350 / 450 / 535
(13.8/17.7/21.1)
350 / 450 / 535
(13.8/17.7/21.1)
Armrest height, Captain Seat mm (inches) 229 / 273
(9 / 10.7)
229 / 273
(9 / 10.7)
