38 | Technical specifi cations
Description 3W 4W
Distance between armrests, Captain Seat mm (inches) 457 - 610
(18 - 24)
457 - 610
(18 - 24)
Back angle, Master Seat ° 45 / 85 / 180 45 / 85 / 180
Seat depth, Master Seat mm (inches) 430 (17) 430 (17)
Seat width, Master Seat mm (inches) 500 (19.7) 500 (19.7)
Back height (excl. headrest), Master Seat mm (inches) 550 (21.7) 550 (21.7)
Seat height (to platform), Master Seat*** mm (inches) 350 / 425 / 535
(13.8/16.7/21.1)
350 / 425 / 535
(13.8/16.7/21.1)
Armrest height, Master Seat mm (inches) 150 / 340
(5.9 / 13.4)
150 / 340
(5.9 / 13.4)
Distance between armrests, Master Seat mm (inches) 500 (19.7) 500 (19.7)
Turning radius (ISO 7176-5) mm (inches) 1030 (40.6) 1600 (63)
Reversing width mm (inches) 1460 (57.5) 1810 (71.3)
Obstacle height (max. user weight) mm (inches) 80 (3.1) 80 (3.1)
Ground clearance (max. user weight / loaded) mm (inches) 70 (2.8) 70 (2.8)
Test data
Test weight 160 kg
Operating force
Drive lever operation < 20 [N]
Resetting the automatic fuse (circuit breaker) < 60 [N]
Electronic switches < 13.5 [N]
Connecting the charger plug < 60 [N]
Technical specifi cations for wheels
Front wheel diameter (3W) mm (inches) 320 x 60 (12.6 x 2.4)
Front wheel diameter (4W) mm (inches) 320 x 60 (12.6 x 2.4)
Rear wheel diameter mm (inches) 360 x 80 (14.2 x 3.1)
Tyre pressure 4W, front wheel bar (psi) 2,5 (36.3)
Tyre pressure 4W, rear wheel bar (psi) 3,5 (50.8)
Tyre pressure 3W, front wheel bar (psi) 2,5 (36.3)
Tyre pressure 3W, rear wheel bar (psi) 3,5 (50.8)
Batteries
Maximum dimensions of batteries (lxbxh) mm (inches) 262 x 173 x 211
(10.3 x 6.8 x 8.3)
Max. battery capacity C20 Ah 74
Max. battery capacity C5 Ah 63
Maximum permitted charging current Ampère 8 RMS
* height of steering column, collapsed, excluding seat
** range dependent on user weight, condition of tyres, type of terrain, condition of battery and weather
conditions with 74 Ah (C20)
*** Seat height < 450 mm (Captain Seat) and < 425 mm (Master Seat) requires an elevated footplate.
