4.2 Operation
See Fig. 000000030.
The scooter is equipped with the following
operating commodities:
A Dashboard with all operating switches
B Operating handles forward / reverse
C Fuse for the lighting. See ‘Lighting fuse’
D Charger connection. See ‘Charging the
batteries’.
E Operating handle for steering-column
adjustment
F Front brake with parking lock
4.2.1 Dashboard
See Fig. 000000040.
F AGF
DB EA C
000000040
B
CF A
E
D
