Technical specifications
46
Test data
Weight test dummy 159 kg
Operating force
Operating-handle power < 60 N
Resetting automatic fuse < 60 N
Electronic switches < 15 N
Parking brake < 60 N
Inserting charging plug < 60 N
Technical data
Diameter front wheel 310 x 108 mm (12.5" x 4.25")
Diameter rear wheels 310 x 108 mm (12.5" x 4.25")
tyre pressure wheels 276 kPa (2.76 Bar)
Batteries Winner 3W Winner 4W Winner
Alpine
Maximum dimensions batteries 324 x 175 x
213 mm
- -
Weight scooter without batteries 54 kg 59 kg 54 kg
Battery capacity 80 Ah/20h - -
Maximum permissible charging voltage 13.6 V - -
Maximum charging current 7 A - -
Connector type A DIN 72311 - -
8.2 Approval
The product meets the following standards:
1. NEN-EN 12182 (1999) Technical tools for the handicapped - General standards
and testing methods October 1997.
2. NEN-EN 12184 (1999) Electrically driven wheelchairs, scooters and associated
charging equipment - Standards and testing methods April 1999.
3. The Winner scooter is classified according to EN12184 (1999) in class C.
4. ISO 7176-8 Requirements and test methods for impact, static, and fatigue strength
July 1998.
5. ISO 7176-9 climate tests for electric wheelchairs and scooters.
6. ISO 7176-14 Standards and test methods for controller systems of electrically
driven wheelchairs 1997.
7. ISO 7176-16 Requirements of resistance to fire May 1997.
8.3 CE-Declaration
The product is in conformity with the provisions of the Medical Devices Directive and
thus has CE marking.
8.4 Authorised service and technical support
If you have any problems or questions concerning this product, please contact your
dealer. Ask us for information about your nearest dealer.
