H&S GM 170 - Optional Features & Accessories; Unloading Auger Extensions

UNLOADING AUGER EXTENSIONS
3’ Folding Auger Extension
The 3’ folding discharge auger extension kit consists of a 3’ length
of auger which is attached on a pivoting mounting bracket to the
end of the 12’ unloading auger.
NOTE:The 3’ folding auger extension must be folded back
and locked in position for transport.
6’ Folding Auger Extension
The 6’ folding discharge auger extension kit consists of a 6’
length of auger which is attached on a pivoting mounting bracket
to the end of the 12’ unloading auger.
NOTE:The 6’ folding auger extension must be folded back
and locked in position for transport.
OPTIONAL FEATURES & ACCESSORIES
-34-
Locked in position for dischatge
Pivoting
Mounting
Bracket
Discharge Auger Cradle Extension
A Discharge Auger Cradle Extension is available to raise the height of the discharge auger in the transport
position to clear most tractor cabs.
