DECAL LOCATION
-44-
Your H&S 170 Grinder-Mixer was manufactured with operator safety in mind. Located on GM 170 are
various decals to aid in operation, and to warn of danger or caution areas. Pay close attention to all the
decals on your Grinder-Mixer.
DO NOT REMOVE ANY OF THESE DECALS. IF DECALS ARE LOST, DAMAGED, OR
IF YOUR GRINDER-MIXER IS REPAINTED, REPLACE DECALS.
REMEMBER: DECALS ARE FOR YOUR PROTECTION AND SAFETY.
Listed below are the decals on your 170 Grinder Mixer. These decals may be ordered individually by part
number, or by ordering as a complete set.
Part # Qty Description
8483 2 Right and Left Side Decal
8485 2 Front and Back Decal
112-11176 1 Shear Bolts - Remove broken shear bolt before replacing
120-2177 1 Pull to Stop
1494A 2 Do not operate this equipment if this decal is exposed.
1494J 4 Do not clean or work on this machine without first disengaging power
1494K 2 Do not remove shields - moving parts inside
1494L 2 Rotating driveline
093466 1 Operate only with 540 RPM PTO
1494P 3 Maintain safe clearance from electrical power lines
2495 1 Keep children away at all times
9194A 3 No step - stay clear
11599 4 Do not go near leaks
32597A 1 Do not operate this equipment if this decal is exposed.
72203A 1 Help avoid injury - Read and understand the operators manual
82602 2 Crushing Hazard
82907A 2 Stay clear of discharge auger
82907B 1 Stay clear of auger extension hinge area
82907C 4 Stay clear - Keep hands and feet away from auger at all times
82907D 4 Stay clear - Rotating parts inside
81209 4 Stay clear - Rotating auger behind this panel
82907F 1 Keep out - Do not enter tank - Keep cover closed
82907G 2 Stay clear - Keep hands out of supplement hopper
82907H 1 Stay clear - Keep hands and feet away from auger at all times
82907I 1 Do not step up on machine while in operation
82907J 1 Operator’s manual is located behind this shield
093366 1 Keep Operator’s Manual Here
82907K 1 Cyclone cover - Open/Close
82907L 2 Never allow riders on this machine
82907M 1 Discharge auger door - Open/Close
093020 7 Grease zerk decal
GM-A 2 95 -135 bushel decal
GM-B 2 55 - 85 bushel decal
5696D 1 Disengage
5696E 1 Engage
DCRED 3 Red Reflector
DCAMB 2 Amber Reflector
11793 1 Attention: Tractor Half PTO
103107 1 Attention: Use Drain Plug
100107 1 Instructions
1 Attention Main Belt
