H&S GM 170 - Dealer Pre-Delivery Check List

DEALER PRE-DELIVERY CHECK LIST
AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS
After the 170 Grinder-Mixer has been completely set-up, check to be certain it is in correct operating order
before delivering to the customer. The following is a list of points to inspect. Check off each item as you
have made the proper adjustments and found the item operating satisfactorily.
 Grinder-Mixer was not damaged in shipment. Check for dents and loose or missing parts.
Report damage immediately to H&S Manufacturing Co., Inc.
 All bolts and fasteners are tight.
 Mixer has been correctly assembled according to instructions in this manual. Wheels are
properly mounted and
wheel nuts are torqued to specs.
 All grease fittings have been lubricated. The transmission and cyclonic reservoir are filled to
proper levels. See
Lubrication Chapter of this manual for details.
 No visible leaks on the hydraulic pump, motors, hoses and fittings.
 Guards and shields are secure.
 Screens fit properly into the mill and the mill cover closes and latches tightly.
 Tires are inflated to 80 PSI (563 kpa).
 Belts are properly adjusted.
 Rear Drive Chain tension is properly adjusted. See Adjustment Chapter of this manual.
 Discharge auger door operates smoothly.
 Decals are in place and legible.
 Lights and wiring functioning properly if applicable.
Connect the Mixer onto a proper horsepower 540 RPM or 1000 RPM (if applicable)
tractor and attach the PTO. Connect the scale and lights if applicable. Run the
Grinder-Mixer and make sure all components operate properly.
 PTO guard turns freely.
 Hydraulic system does not leak under pressure.
 Electronic Scale (if provided) operates properly.
 Implement and all components are functioning properly.
-3-
(Remove Dealer File Copy At Perforation)
SWINGING INTAKE AUGER (SIA) (If applicable)
 Guards, shields, and attaching hardware are in place and properly secured.
 SIA lifting, locking and supporting mechanisms function correctly. Counter-balance spring and
brake are properly adjusted. See
Adjustments Chapter of this manual.
 Transport lock mechanism engages and disengages correctly. Safety locking clip is attached
to the transport bracket.
 Hydraulic motor and speed control levers operate properly during operation.
 Decals are in place and legible.
Serial Number
Dealer’s Name
Signature of Pre-Delivery Inspector
Model Number
Inspection Date
