H&S GM 170 - Page 55

FRAME
-53-
NOTE: * MEANS NOT SHOWN
FIGURE 1
ITEM
1
2
3
4
5
6
7
8
*
9
10
11
12
13
14
15
16
17
18
19
20
21
22
*
23
PART #
GM72
GM73
GM74
GM396
12N13
YNHX32010
GM76
GM77
F97
GM78
GM79
B90
B91
B91A
YBSD20010
26G4A
B94A
B94
YWFL28005
YNSL28005
YPCT05020
B2
RG73
GM394
YNWL20005
DESCRIPTION
FRAME
HITCH SHAFT
HITCH
JACK
JACK PIN & CHAIN
HEX NUT, 1"-8 PLATED
TANK SIDE SUPPORT
TANK BACK SUPPORT
SMV BRACKET
OIL TANK BRACKET
SPINDLE
SEAL
INNER BEARING
INNER RACE
STUD 5/8"-18
HUB (821)
OUTER RACE
OUTER BEARING
WASHER, FLAT, 7/8" USS
HEX NUT, SLOTTED, 7/8"-14
COTTER PIN, 5/32" X 1-3/4"
HUB CAP
WHEEL (W-51350)
TIRE (12.5L x 15 20 PLY)
LUG NUT 5/8"-18
