HYDRAULIC CYLINDERS
ITEM PART # PART # PART # DESCRIPTION
1. 23N142A DWM192 16SV157A Clevis Cap
2. 23N143A HD188 HD189 Rod Cap
3. 23N144 DWM194 HD198 Piston
4. 16SV168A HD190 HD191 Rod
5. 16SV169 HD192 HD193 Cylinder Tube
6. 16SV170 HD194 HD195 Tie Rod
7. 23N148 DWM198 DWM198 Piston Nut
8. 23N149 DWM199 DWM199 Plug
9. 23N150A DWM200 DWM200 Rod Clevis
10. 23N151 HD196 HD197 Seal Kit
11. 16SV171A HD135 HD136 Hydraulic Cylinder
-37-
FIGURE 7
FRAME WIDTH
LIFT CYLINDER
WING CYLINDER
2” x 10”
3” x 8”
3-1/2” x 60”
To Next Page
