A
ctilino
The Actilino a
s Braille Display
Page
85
Control Key/Braille Dot
Function
[SPC + 2 3 4]
Goes to the status bar
[SPC + 3 4]
Speak page number or row
s b
eing d
isplayed
[SPC + 4 7] iPad only
Move to next container
[SPC + 1 7] iPad only
Move to previous container
[SPC + 4
or
5]
Moves through the list
[SPC + 2]
Pan Braille to the left
[SPC + 5]
Pan Braille to the right
[SPC + 1 2 3 4]
Pause or continue speech
[SPC + 1 3 4]
Toggle speech on and off
[SPC + 1 2 3 4 5 6]
Toggle Screen Curtain on and off
[SPC + 2 3 6]
Toggle between 6-dot and 8-dot Braille
[SPC + 1 2 4 5]
Switch between contracted and uncontracted
braille
[SPC + 3 4 5]
Activates the Volume Up button
[SPC + 1 2 6]
Activates the Volume Down button
[SPC + 1 2 3 4 6]
Set label
[SPC + 1 3]
Keyboard help
[SPC + 2 3 4 5]
Activates the Tab key
[SPC + 1 2 5 6]
Activates Shifl Tab
[SPC + 1 5]
Activates the Return key
[SPC + 8]
Activates the Return key
[SPC + 1 4 5]
Activates the Delete key
[SPC + 7]
Activates the Delete key
[SPC + 2 5 6]
Select text
[SPC + 2 3 5]
Deselect text
[SPC + 1 4]
Copy
[SPC + 1 3 4 6]
Cut
[SPC + 1 2 3
6]
Paste
[SPC + 1 3 5
6]
Undo typing
[SPC + 1 4 6]
Activates the Eject key
[SPC + 3 4 5 6]
Scroll up one page
[SPC + 1 4 5 6]
Scroll down one page
You can find the complete list of Braille commands for VoiceOver at
https://support.apple.com/en-en/HT202132
.
84
86
Table of Contents
Default Chapter
2
Table of Contents
2
1 General
7
Preface
7
Actilino at a Glance
7
Top of the Unit
7
Right Side of the Device
9
Left Side of the Device
9
Front Side of the Device
9
Bottom of the Device
9
Conventions Used in this Manual
9
2 Installation
10
Package Contents
10
Software Installation
10
Connecting the Power Supply
11
Connecting the Interface Cable
12
Connecting an External USB Keyboard
12
The Carrying Case
12
Installation of the Bluetooth Tie-In
13
Bluetooth-PC Tie-In
13
Bluetooth Apple Ios Device Tie-In
13
Bluetooth-Android Device Tie-In
14
Technical Specifications
14
3 Start up
16
Version Information
16
Turning the Power on
16
Basic Operation
17
Chords
17
Signal Tones
17
System Messages
18
Checkboxes
18
Radio Buttons (1 of X)
19
System Files
19
Energy Saving Features
19
The SAVE Mode
19
4 Quick Start
20
The Actilino as Braille Display
20
How to Use the Actilino to Make a Call with an Iphone
20
The Actilino as Notepad
21
Navigating the Menu
21
Context Sensitive Help
21
Writing a Note
21
Saving a Note
22
Opening a File
22
Transferring Data between the Actilino and a PC
22
Transferring a File Using Htcom from the Actilino to the PC
23
Transferring a File Using Htcom from the PC to the Actilino
24
5 Operation of the Actilino
25
The Menu System
25
Menu
25
F)Ile
25
New File
25
Previous File
26
New Directory
26
File and Folder List
26
C(A)Lculator
28
S)Cheduler
30
Entering a New Appointment (New Entry)
30
Entering and Editing Appointments
31
Entering Appointments with Variables (Recurring Appointments)
32
A few Notes on Entering Appointments
33
The Appointment Schedule
33
Full Text Search Within Appointments
34
Appointment Editing Menu
35
Information Regarding Past Appointments
36
Resources Management
36
Backing up the Scheduler Data
36
C)Lock
36
T)Ime
37
D)Ate
37
Set (A)Larm
37
Set (C)Lock
37
S)Topwatch
38
C(O)Untdown
38
M)Usikbraille
38
Player (L)
39
G)Ames
40
H)Angman
40
P)C Mode
40
B)Raille Sets
41
Creating a Braille Character Set
41
Loading Braille Character Sets
41
Selecting and Activating Braille Tables
42
D)Elete Selection
43
I)Nfo
43
M)Emory Usage
43
B)Attery Stats
43
K)Eyboard Layout
44
S)Erial Number
44
V)Ersions
44
Maintenance Info
45
System Information
45
O)Ptions
45
Dots Braille
45
Hotkeys (A)Ctivate Objects
45
H)Ighlight Hotkeys
46
Show S(Y)Stem Files
46
Show F(O)Lders First
46
Q)Uick Entry
46
Show File Attri(B)Utes
46
Auto Switch E(X)T Keyboard
46
Sw(I)Tch Actilino Auto off
47
S)Tartup Mode
47
T)One Signals
48
D)Ate and Time Format
48
I)Nput Indication
49
Dot (F)Irmness
50
Atc S(E)Nsitivity
50
Sta(N)Dby
50
Language
50
Mass Storage
50
Battery Charge Enable
51
Low Energy Braille Output
51
Battery Calibration: See Manual
51
R)Estore Factory Defaults
51
The Editor
53
Overview of Editor Functions
53
Dialogs and Confirmation of Actions
53
Entering and Deleting Text
54
Reading Text
54
ATC Within the Editor
55
Moving the Cursor
55
Editing Modes (SPC+2 4 = Chord I)
56
Calculator Function
57
Status Display (SPC+2 3 4 7 = Chord S)
57
Set Mark (TU+TD)
57
Jump to Mark (SPC+1 3 4 = Chord M)
58
Delete Mark (TU+TD, Select Name, SPC)
58
Block Functions
58
Marking the Beginning of a Block [SPC+TRC]
58
Copy (SPC+1 4 = Chord C)
59
Cut (SPC+ 1 3 4 6 = Chord X)
59
Paste (SPC+1 2 3 6 = Chord V)
59
Exchange Mark and Cursor (SPC+7 8)
60
Deleting a Text Block (SPC+ 1 3 4 6 7 = Chord X, SPC+1 2 = Chord B)
60
Saving a Block to a File (SPC+2 3 4 = Chord S)
60
Searches
60
Incremental Search (SPC+1 2 4 = Chord F)
61
Buffered Search
61
Backward Search (SPC+1 2 4 7 = Chord F)
62
Replace (SPC+1 2 3 5 = Chord R)
62
Opening Additional Files
62
Switching between Open Files (SPC+5 6 8 or SPC+2 3 7)
63
Suspending the Editor (SPC+1 2 3 4 5 6)
63
Saving Files (SPC+2 3 4 = Chord S)
63
Quick Transfer of Files or Blocks of Text to a Connected Device
65
Chord E)
65
Closing a File and Quitting the Editor (SPC+1 5 = Chord E)
65
Activating PC Mode from the Editor (SPC+1 2 3 4 = Chord P)
65
Help (SPC+1 2 5 = Chord H)
66
The Editor's Setup Menu (SPC+1 3 6 = Chord U)
66
Window Scrolling (Global)
66
Scroll Time (Global)
67
Indicate Empty Lines (Global)
67
Automatic Scrolling (Global)
67
Dialog Timeout (Global)
67
Warn Timeout (Global)
67
Result Position or [C]
68
Keep Expression or [C]
68
Find Exact (Global)
68
Margin Action (Global)
69
Right Margin (Global)
69
Word Wrap (Global)
69
Tab Mode (Global)
69
Tab Stops (Global)
69
Tab Width (Global)
70
Line End (Individual File)
70
Insert Cursor (Global)
70
Edit Mode (Individual File)
70
Scroll Speed (Global)
71
Saved Position (Individual File)
71
Display Mode (Individual File)
71
Step Size (Global)
71
Match Column (Global)
71
Important Instructions Regarding the Editor
72
Controlling the PC from the Actilino's Keyboard [SPC+1 2 7] (Chord B)
73
Table of Key Commands for Controlling the PC
74
6 External Keyboard
76
General
76
Keyboard Keys
76
Alphanumerical Character Inputs
77
Numerical Pad
77
Function Keys
77
Navigation Keys
77
Special Keys
77
Status Indicators
77
7 The Actilino as Braille Display
78
Screen Reader Using Windows: Example Window-Eyes
78
Overview
78
Screen Readers Using Windows: Example JAWS
80
Overview
80
Screen Reader Using Windows: Example Hal/Supernova
82
Overview
82
Voiceover: Screen Reader for Apple Ios Devices
84
8 Operation Settings for Handy Tech Braille Displays
86
Connection
86
Atc
87
Status Cells
87
Key Actions
87
Key Lock
88
Fast Keys
88
Repeat Keys
88
Miscellaneous
89
Info
89
9 Active Tactile Control (Atc)
90
ATC Assistant for Reading or Learning
91
Tips for Utilizing ATC to Learn Braille
92
Tips for Utilizing ATC for the Experienced Braille Reader
93
ATC-Monitor Settings
94
10 Battery Management
95
Battery Charging
95
Battery Capacity Display
95
Automatic Recognition of Low Voltage
96
Replacing the Battery
96
11 Important Information
98
Start-Up Procedures
98
Self-Check of the File System
98
Saving Files in Case of Fatal Errors
99
Symbols
99
Safety Information under the Standards for Medical Devices
99
General Safety Information
99
Handling the Actilino
101
Warranty
101
Technical Support
101
12 List of Key Combinations
103
Navigating the Menu System
103
Editor Functions
103
Keys in PC Mode
104
Fixed Key Functions on External Keyboard
104
13 Error Messages
106
English Language Error Messages
106
Fatal Errors
106
General Errors
107
Warnings and Messages
107
Error Messages from the Message File
108
General Messages
108
File System Messages
108
Editor Messages
109
14 Copyright Notice
112
