TABLE OF CONTENTS
Introduction 3
Additional Equipment Required 4
Tools and Supplies Required 4
Contents of Kit 5
Field Equipment Required 6
Optional Field Equipment 7
Section 1: Assembling the Wings 8
Section 2: Joining the Wing Halves 9
Section 3: Installing the Aileron Servos 13
Section 4: Bolt Wing to Fuselage 14
Section 5: Installing Horizontal Stabilizer 14
Section 6: Installing Vertical Fin 16
Section 7: Tail Dragger or Tricycle Landing Gear 17
Section 8: Installing the Tail Wheel Assembly 18
Section 9: Hinging the Rudder and Elevator 20
Section 10: Installing the Control Horns 20
Section 11: Installing Main Landing Gear Block — Tail Dragger 22
Section 12: Installing Main Landing Gear Block — Tricycle 23
Section 13: Installing the Main Landing Gear 23
Section 14: Installing the Nose Gear 25
Section 15: Assembling and Installing the Fuel Tank 26
Section 16: Installing the Servo Tray 28
Section 17: Installing the Engine 29
Section 18: Installing the Spinner 30
Section 19: Installing the Radio System 30
Section 20: Installing the Aileron Linkages 32
Section 21: Assembling Elevator & Rudder Pushrods 33
Section 22: Installing the Throttle Linkage 35
Section 23: Installing the Nose Wheel Linkage 36
Section 24: Control Throw Recommendation 37
Section 25: Balancing the Super Stick 37
Pre-Flight Check 38
Pre-Flight at the Flying Field 39
AMA Safety Code 40
