INSTALLING THE MAIN LANDING GEAR
13
2 . Locate the three hole indentations in the bottom of
the fuselage that are directly underneath where you
installed the landing gear block inside the fuselage.
➤ Note:If you are building your Super Stick as a tail
dragger,use a small wood screw (like a servo
mounting screw) for the middle hole of the landing
gear.
➤ Hint:Do not use the supplied bolt in this middle
location as it will interfere with the fuel tank. Instead,
use a small wood screw (not supplied).
3. From the bottom of the fuselage,drill out the two
outside holes with a 5/32
"
drill bit through the landing
gear block. Drill the middle hole using an 1/16
"
drill
bit.
4. Bolt the landing gear onto the fuselage with the
included hardware. Take the bolt and insert through
the landing gear and secure it with another washer
and a nut on the inside of the fuselage.
