–– Locate the installing holes and Strike theLocate the installing holes and Strike the
edge of the driving wheels evenly andedge of the driving wheels evenly and
symmetrically to the perfect match of thesymmetrically to the perfect match of the
new driving wheels.new driving wheels.
––
Screw the 12 socket hexagon screwsScrew the 12 socket hexagon screws
which is used to fix the driving wheelswhich is used to fix the driving wheels
with a S=5mm hex wrench.with a S=5mm hex wrench.
CAUTIONCAUTION
Screw up the bolts in a symmetricalScrew up the bolts in a symmetrical
way by 2 times.way by 2 times.
Apply appropriate torque to screwApply appropriate torque to screw
up the bolts. Do not overexert whichup the bolts. Do not overexert which
might do damage on the thread ormight do damage on the thread or
lead to future removing problem.lead to future removing problem.
–– Apply the fixaApply the fixation clamp otion clamp of the motorf the motor
signal wire back and fix it.signal wire back and fix it.
The replacement of driving wheels isThe replacement of driving wheels is
completed.completed.
