9
forklift has no choke line. When turn off
the key switch, the engine will stop.
Forward-reverse lever [20]
[Electrical Switch]
The forward reverse lever of truck
installed with electronic reserving is set
on the left of turning rod。
Forward—Forward N—neutral
After
allocation
—backward
Caution:
Do not forget to place the forward-reverse
lever in the neutral position before starting
the engine.
Body and others
Load bracket
Load bracket can ensure stabilization
when loading the goods. It’s forbidden
to use the forklift truck without the load
bracket.
Seat and seat adjusting lever
Adjust operator’s seat to position,
which is comfortable for you and
provides easy access to all hand and foot
controls. The seat is unlocked by
moving the adjusting lever to the right.
Before proceeding with work, adjust
operator’s seat and make sure that it is
securely locked.
Warning!
a. Before adjusting the lever, you’d
better turn off the key switch.
b. Must stop the truck to adjust the
seat .
Seat weight support adjusting
Use spanner to adjust the bolt
which is at the back of seat, or adjust the
knob for supporting the weight on seat at
the lift side of seat, adjust the hanging’s
weight basing on person’s weight.
It’s better to sit on the seat when
adjusting.
Seat switch
While you are on the vehicle and
wearing the Safety belt, at the same time,
your back and waist should close to the
seat as much as possible.
Check whether the bolts which fixed
seat belt were loose frequently. It is
forbidden to use the Safety belt when
the belt was tie a knot. Do not let the
belt press on the hard or fragile objects.
And also do not make friction with the
sharp edge to avoid damaging the belt.
Do not let the seat back tilted too much;
otherwise the safety belt will not be able
to correctly elongation.
The components which are on the
safety belt can not be removed randomly.
If the safety belt used frequently, you
