11. Performance parameters of R series IC forklift
1—1.8t R series
Model CPQD10N-RW7 CPQD15N-RW7 CPQD18N-RW7
Rated capacity Kg 1000 1500 1800
Load center mm 500 500 500
Max. lifting height mm 3000 3000 3000
Free lifting height mm 155 155 155
Max lifting speed mm/s，full
load
460 510 510
Tilting angle F/B 6°/12° 6°/12° 6°/12°
Max traveling speed Km/h 14.5 14.5 14.5
Ground clearance mm 115 115 115
Min turning radius mm 1925 1970 2000
Max grade ability % 20 20 20
wheelbase mm 1400 1400 1400
Wheel thread (F/R) mm 890/900 890/900 890/900
Service weight Kg 2450 2740 2930
Overall dimension(L×W×H)
(exclusive forks)
2225×1080×1995 2265×1080×1995 2300×1080×1995
Tyre (F/R)
6.5-10-10PR/2
5.00-8-10PR/2
6.5-10-10PR/2
5.00-8-10PR/2
6.5-10-10PR/2
5.00-8-10PR/2
Voltage/Capacity Ah 12/60/20h 12/60/20h 12/60/20h
type
WanFeng WF491GP gasoline
Displacement cc 2237
Rated capacity/rpm 41 KW/2800r/min
Diesel
Max torque/rpm 161N·m/ 2200 r/min
