64
Model CPQD10N-RW21 CPQD15N-RW21 CPQD18N-RW21
Rated capacity Kg 1000 1500 1800
Load center mm 500 500 500
Max. lifting height mm 3000 3000 3000
Free lifting height mm 155 155 155
Max lifting speed mm/s 460 500 500
Tilting angle F/B 6°/12° 6°/12° 6°/12°
Max traveling speed Km/h 14.5 14.5 14.5
Ground clearance mm 115 115 115
Min turning radius mm 1925 1970 2005
Max grade ability % 20 20 20
wheelbase mm 1400 1400 1400
Wheel thread (F/R) mm 890/900 890/900 890/900
mechanical 2395 2685 2875
Service weight
Kg
hydraulic 2450 2740 2930
Overall dimension(L×W×H)
(including forks)
3145×1080×2110 3185×1080×2110 3220×1080×2110
Tyre (F/R)
6.5-10-10PR/2
5.00-8-10PR/2
6.5-10-10PR/2
5.00-8-10PR/2
6.5-10-10PR/2
5.00-8-10PR/2
Voltage/Capacity Ah 12/60/20h 12/60/20h 12/60/20h
type NISSAN K21
Rated
capacity/rpm
37KW/2300 r/min
Max torque/rpm 142N·m/1600 r/min
gasoline
Displacement cc 1982
