HANGCHA CPQD18N-RW21 - Page 79

75
Model CPCD20N-RW33M CPCD25N-RW33M
Rated capacity Kg 2000 2500
Load center mm 500
Max. lifting height mm 3000
Free lifting height mm 150
Max lifting speed
mm/s，full load
500 500
Tilting angle F/B 6°/12°
mechanical /
Max traveling
speed Km/h
hydraulic 19
Ground clearance mm 105
Min turning
radius mm
2175 2235
2t /
Grade full
load %
2.5t 20
wheelbase mm 1665
Wheel thread (F/R)mm 965/970.5
Service weight Kg 3440/3765
2T 3615×1155×2120
Overall
dimension
(L×W×H)
(exclusive forks)
2.5T 3690×1155×2120
Tyre (F/R)
7.00-12-12PR/2
6.00-9-10PR/2
Voltage/Capacity Ah 12/100/20h
type
YANMAR 4TNE98-BQFLC diesel engine
Displacement cc 3319
Rated capacity /rpm 44.3KW/2300r/min
Diesel
Max torque /rpm 206N·m/ 1700 r/min
