2.5 Standard technical data
The following technical data are all standard data. Our company reserves the right of alteration
and extension.
Characteristics
Model
CBD15-A2MC1
CBD15-A3MC1
CBD15-A3MC2
CBD15-A3MC1-I
CBD15-A3MC2-I
Operator type
Pedestrian Pedestrian
Load capacity Q (kg)
1500 1500
Load center c(mm)
600 600
Weight Service weight with battery kg
180 180
Wheels
﹠
Tyres
Tyres type
PU PU
Tyre size, front mm
1×Φ210×70 1×Φ210×70
Tyre size, rear mm
2×Φ80×90 2×Φ80×90
Additonal wheels(dimensions) mm
/ /
Wheels, number front rear(x=driven wheels)
1×/4 1×/4
Dimensions
Lift height h3(mm)
120 120
Overall length L1(mm)
1640 1640
Overall width b1(mm)
568 568
Ground clearance, center of wheelbase m2(mm)
30 30
Outer turning radius, min Wa(mm)
1400
1)
1400
1)
Performa
nce
Travel speed, laden/unladen km/h
4.8/5.0 4.8/5.0
Lift speed, laden/unladen mm/s
36/53 36/53
Max Gradeability, laden/unladen %
6/15 6/15
Motor﹠
Battery
Drive motor power kW
0.65 0.65
Lift motor power kW
0. 8 0. 8
Battery voltage, rated capacity V/Ah
2×12/70 24/40
Controller mode Curtis DC Curtis DC
Note: 1) Load section lowered+56mm.
