HANGCHA Mini CBD15-A3MC1 - Page 75

FLASH CODE
NAME
CAN INDEX
POSSIBLE CAUSES
FAULT
TYPE
SET CONDITION CLEAR CONDITION FAULT ACTIONS
54
Pump SRO
Fault
0x2330
• Incorrect operation sequence
• Defective switch
1 The lift input is active
when the keyswitch is
turned on.
Cycle the keyswitch. Shut down lift
2 The lower input is active
when the keyswitch is
turned on.
Cycle the keyswitch. Shutdown liftand lower
3 The controller did not
receive CAN lift or CAN
lower PDO messages
within 2s after startup.
The Lift Input State and
Lower Input State must
both be off.
Shut down liftand lower
4 The Lift On Interlock
parameter specifies On
and the lift input is active
when the interlock state
changes to on.
The Lift Input State and
Lower Input State must
both be off.
Shut down lift
5 The Lower On Interlock
parameter specifies On
and the lower input is
active when the interlock
state changes to on.
The Lift Input State and
Lower Input State must
both be off.
Shut down liftand lower
55
EMR SRO
Fault
0x2340
• Defective emergency
reverse switch
• Incorrect operation sequence
1 The emergency reverse
switch is active when the
keyswitch is turned on.
Cycle the keyswitch. Shut down throttle
2 The emergency reverse
switch is active when
the interlock input is
turned on.
Turn off the emergency
reverse switch.
3
The absolute value
of the throttle demand
is greater than 10%
after an emergency
reverse operation.
Release the throttle.
56
Creep SRO
Fault
0x2350
Incorrect operation sequence 1 The creep input is on
when the keyswitch is
turned on.
Turn off the creep input. Shut down throttle
2 The creep input is on but
the interlock state has
been off for 40ms.
Turn off the creep input.
3 The interlockstate is on for
40msduringcreepmode.
Turn off creep mode and
the interlock.
4 The controller cannot
abort the creep brake
state after the Interlock
Brake Timeout expires.
Turn off creep mode and
the interlock.
57
Inching SRO
Fault
0x2351
Incorrect operation sequence 1 The inching forward or
inching reverse input is
on when the keyswitch is
turned on.
Turn off the inching
forward and inching
reverse inputs.
Shut down throttle
2 The inching forward or
inching reverse input is on
but the interlock state has
been off for 40ms.
Turn off the inching
forward and inching
reverse inputs.
3 The interlockstate is on for
40ms during inching mode.
Turn off inching forward,
inching reverse and
interlock inputs.
