16
INSTALLATION
Reservoir Immersion Installation
Detailed below a representation of a reservoir immersion installation scheme together with the
relevant components and the pH probe screwed into the threaded end of a user supplied pipe and
fastened with a bracket.
Position Description
1 Electrode holder tube
2 Bracket (user supplied)
3 Reservoir
4 Electrode
