SPECIFICATIONS
5. SPECIFICATIONS
Range 0.00 to 50.00 FTU*
50 to 1000 FTU*
Resolution 0.01 and 1 FTU*
Accuracy ±0.5 FTU* or
±5% of reading (whichever is greater)
Calibration 3 point (0, 10 and 500 FTU*)
Light Source Infrared LED
Light Source Life Life of the instrument
Light Detector Silicon photocell
Data Logging 199 measurements, on-demand
PC Connection Through serial port, using HI920011
connection cable and HI92000
Windows® compatible software
Battery Type 4 x 1.5V AA alkaline batteries
Battery Life Approx. 60 hours of continuous use or 900
measurements
Auto-off After 5 minutes of non-use
Environment 0 to 50°C (32 to 122°F);
RH max 95% non-condensing
Dimensions 220 x 82 x 66 mm
(8.7 x 3.2 x 2.6”)
Weight 510 g (1.1 lb.)
* 1 FTU = 1 NTU
