Hantek 365A - Temperature Measurement

Operating Data Logger
USER’S MANUAL 32
1) Click the V/A/OHM/CAP key.
2) Connect the black lead into the COM banana jack input and the red lead into the V//Ω/C
banana jack input.
3) Connect the red and black test leads to the tested device. The value is shown on the screen.
4) Click key then is displayed on the top of the screen. The saved reference
value is displayed beside.
Then, the following figure will be displayed on the screen.
Figure 2-21 Relative Measurement
2.8 Temperature Measurement
The series of Bluetooth/USB Data Logger can measure temperature.
1) Click the T key.
2) Connect the black lead into the mA banana jack input and the red lead into the V//Ω/C banana
jack input.
3) Connect the red and black test leads to the tested device. The value is shown on the screen.
Figure 2-22
