Hantek HT8000 Series User Manual

6
3. Main Specifications
Electrical Specification
Model
HT8050
HT8100
Bandwidth (-3dB) 50MHz 100MHz
Rise time
7ns
3.5ns
Accuracy ± 2%
Attenuation
1/50, 1/500
Input resistance
Between each input to ground: 4MΩ
Between inputs: 8MΩ
Input capacitance
Between each input to ground: 7pF
Between inputs: 3.5pF
Maximum
measurable
differential voltage
1/50: 130V (DC + peak AC)
1/500: 1300V (DC + peak AC)
Maximum input
voltage-to-earth
1000Vrms, C AT Ⅱ
600Vrms, C AT
Ⅲ
Noise
1/50: ≤ 1.5mVrms
1/500: ≤ 1mVrms
Linearity
±1%
Delay time 20ns±1ns
CMRR
DC: ≥80dB
100Hz: ≥ 60dB
1MHz: ≥ 50dB
