3
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Motor Housing 1
B Upper Mounting Bracket 1
C Receiver (preassembled to Upper Mounting Bracket [B]) 1
D Lower Mounting Bracket (preassembled to Motor [E]) 1
E Motor 1
F Switch Housing (preassembled to Motor [E]) 1
G Switch Housing Cap (preassembled to Light Kit [H]) 1
H Light Kit 1
I Finial Cap (preassembled to Light Kit [H]) 1
J Finial (preassembled to Light Kit [H]) 1
K Glass Shade 1
L Blade Arm 5
M Blade 5
N Bulb 2
O Remote Pack 1
P Large Washer (preassembled to Light Kit [H]) 1
Q Hex Nut (preassembled to Light Kit [H]) 1
R Mounting Bracket Screw (preassembled to Lower Mounting Bracket [D]) 4
S Switch Housing Screw (preassembled to Switch Housing Cap [G]) 3
T Motor Housing Screw (preassembled to Upper Mounting Bracket [B]) 4
U Blade Balancing Kit 1
V Motor Screw (preassembled to Motor [E]) 10 + 1 extra
W Spring Washer (preassembled to Lower Mounting Bracket [D]) 4
A
B
D
C
E
J
I
H
G
F
K
L
M
N
O
P Q R S T U V W
